Facts and figures
Technical data
| Products: | T-Fittings, bends | hydroforming free form |
|---|---|---|
| Clamping force (KN): | from 6.000 to 150.000 | |
| Diameter (mm): | up to 1.016 | up to 150 |
| Wall thickness (mm): | 0,8 – 35 | 0,7 to 10 |
|---|---|---|
| Component length (m): | max. 2,5 | individual |
Forming process
Hydroforming
T-Fittings
Any questions?
Your contact person is here for you!
Would you like to find out more about our hydroforming machines and innovative technologies? No problem - you are welcome to contact me.
Konstantin Zimmer, your AWS specialist for hydroforming processes
Advantages
- Different materials and wall thicknesses can be used in the same tool
- Multiple parts per forming cycle possible
- Process-independent of the insert pipe - welded or seamless
- Reduction of process steps, parts integration
- Maximum dimensional, shape and repeat accuracyLow energy consumption in series production thanks to AWS pump storage system
- Low component weight, high material and fatigue strength thanks to work hardening
- Short cycle times thanks to innovative pressure generator concept
- Also suitable for the production of bi-metal/cladding fittings
- Automatic loading and unloading systems
